7-6 MODEL CHARTS AND TECHNICAL SPECIFICATIONS
*Availability subject to the laws and regulations of individual countries.
All speciÞcations shown are typical. Radios meet applicable regulatory requirements.
Receiver
*Frequencies - Full Bandsplit
VHF 136 - 174 MHz
UHF1 403 - 470MHz
UHF2 450 - 527MHz
Frequency Stability
(-30¡C to +60¡C) (+25¡C reference)
0.00025%
Sensitivity (12 dB SINAD) EIA 0.25 µV
Intermodulation EIA 70 dB
Adjacent Channel Selectivity
60 dB @ 12.5 kHz
70 dB @ 20/25 kHz
Spurious Rejection -70 dB
Rated Audio 0.5W
Audio Distortion @ Rated Audio 3%
Hum and Noise
-45dB@ 12.5kHz
-50dB@25kHz
Audio Response (300-3000Hz) +1 to -3dB
Conducted Spurious Emission
-57dBm<1GHz
-47dBm>1GHz
