Keyboard Wedge Interface 6 - 5

Keyboard Wedge Country Types (Country Codes)

Scan the bar code corresponding to the keyboard type. If the keyboard type is not listed, see Alternate Numeric

Keypad Emulation on page 6-8.

*North American

German Windows

French Windows

French Canadian Windows 95/98

French Canadian Windows XP/2000

Spanish Windows

Italian Windows
