10
English
Replacing the Battery
1. Slide the fixing clip as illustrated.
2. Lift the top of the battery cover out.
3. Push the battery against the hook.
4. Lift the battery out.
5. Replace the battery as per the installing procedure.
Charging the Battery
Motorola approved chargers provide optimum performance. Other
chargers may not fully charge your Motorola Lithium-Ion battery or
may reduce the life of the battery.
The TCR1000 can be either On or Off during charging.
Li-Ion batteries charge within the temperature range of 0° C to 45°C.
If a battery is outside this temperature range, no charge current is
supplied to the battery.
DO NOT connect any charger to the mini-USB Extended Battery
connector.
2
1
2
1
