Connecting the Extended Battery
1. Insert the strap into the hole at the back bottom of the terminal.
2. Hook the strap onto the knob of the extended battery.
3. Connect the mini-USB plug and tighten it using the plug screw.
Mini-USB Plug
Plug Screw
Extended Battery
Extended Battery Strap
Knob
