TCR1000 Overview
Controls and Indicators
The numbers below refer to the illustration on the inside front cover.
Number Description
Radio Unit
1
CE Connector
Connects Remote Control Unit and audio accessories.
Used for battery charging, terminal programming, and
keyloading.
2
Antenna Connector
3
On-Off Key
Power on or off the terminal.
4
Encryption Keys Button
Used for loading and deleting encryption keys.
5
LED Indicator
Shows operations states of the terminal.
6
Extended Battery Strap Anchor
7
Extended Battery Connector
Remote Control Unit
8
PTT Button
Initiates half-duplex calls.
9
Talkgroup Rotary Switch
Selects talkgroups.
10
Reset Button
11
Option Button
Used to enable or disable pre-programmed functions, for
example: Transmission Inhibit Mode, Whisper Mode, TMO/DMO
toggling.
12
USB Connector
Connects Remote Control Unit to the terminal.
13
TMO/DMO/Emergency Button
Used to enter the selected pre-programmed mode.
14
Tone Button
Sends a tone indication to the selected group.
15
Remote PTT Connector
16
Volume Up and Down Buttons
Adjust earpiece audio volume.
