Icon Description
Repeater Mode – Indicates that radio is operating as a repeater in Repeater Mode.
The icon blinks when the radio is in Repeater Background Mode.
DMO Gateway Communication Mode – Indicates that gateway is selected. The icon
has the following status:
• Solid – when the radio is synchronized with the gateway.
•
Blinking – when the radio is not synchronized or during attachment.
• No icon – during radio-to-radio and repeater communication.
DMO Repeater Communication Mode – Indicates that the Repeater or
GW + Rep
option in DMO Mode is selected. The icon has the following status:
• Solid – when the radio has detected the repeater (for example, when the radio
receives a presence signal).
• Blinking – when the radio has not detected the repeater or during attachment.
• No icon – during a radio-to-radio and gateway communication.
General Icons
All Tones Off – Indicates that:
• Volume is set to 0 (when Volume Adj. Mode is set to Common
).
• Both simplex and duplex ring volume is set to 0 (when Volume Adj. Mode is set
to Individual).
Simplex Ring Muted – Indicates that simplex ring volume is set to 0 and duplex ring
volume is set to more than 0.
Duplex Ring Muted – Indicates that duplex ring volume is set to 0 and simplex ring
volume is set to more than 0.
/
Speaker Off – Indicates that audio will not sound through the speaker.
/
Audio Profile Selected – Indicates that an audio profile associated with a particular
icon is active. For details on audio profiles available on the radio, contact your
service provider.
Horn and Lights – Indicates that an external alarm, for example, horn and lights is
activated.
GNSS
• Solid – the radio has a location fix.
• Blinking – the radio is acquiring a location fix. This feature is an optional setting
and may not be enabled on your radio.
RUI Logged on – Indicates that you are logged on into the radio.
RUI Pseudo Log On – Indicates that you are in pseudo logged on state.
RUI Packet Data – Indicates Pseudo Log On state when the Packet Data feature is
activated and active data session is in progress.
RUI Packet Data – Indicates Pseudo Log On state when the Packet Data feature is
activated and the external device sets up data connection with the radio.
68015000180-MR
