Table 3: Controls and Indicators – Telephone Style Control Head (TSCH)
Annotation Description
1 Display
Provides alphanumeric text and images within 65,536 colors and 240 x 320 pixels
with backlighting and scalable fonts.
NOTE: Before using your radio for the first time, remove the plastic lens
protector from the display.
2 Menu key
Press to enter the main menu and the context-sensitive menu.
3 Soft keys
Press Left or Right Soft key, to select the option that appears on the screen
above it.
4 Send key
• Press to initiate or answer duplex calls, or send messages.
•
Press in home screen to enter Recent Dialed Calls.
5 Alphanumeric Keypad
Use the keypad to enter alphanumeric characters for dialing, contact entries, and
text messages.
6 FUNCTION key 1
By default:
• Short press – activates/deactivates the horn and lights feature.
• Long press – adjusts the backlight.
7 FUNCTION key 2
By default:
• Short press – turns the speaker on/off.
• Long press – activates/deactivates the screen saver.
8 On/Off/End/Home Key
• Press and hold to turn on/off your radio.
• Press to end calls.
• Press to return to the home screen.
9 Navigation key
Press Up, Down, Left, or Right Navigation key for list scrolling, while moving
around the menu hierarchy, or for alphanumeric text editing.
From the home screen, press to activate one of the following:
• Down Navigation key – enters Recent Calls menu item.
• Up Navigation key – changes My Groups talkgroup folder.
• Left and Right Navigation key – toggles through the talkgroups.
10 Micro USB Port
Provides connection between the radio and a computer.
11 FUNCTION key 3
68015000180-MR
Chapter 2 : Getting Started
24
