6809471A72-O April 14, 2004 19
Level 1 and 2 Service Manual Tools and Test Equipment
Tools and Test Equipment
The following table lists tools and test equipment recommended for disassembly
and reassembly of V80 telephones. Use either the listed items or equivalents.
Table 1. General Test Equipment and Tools
Motorola Part Number
1
Description Application
RSX4043-A Torque Driver Used to remove and replace screws
—
Torque Driver Bit T-6 and Driver Bit T-3
Plus, Apex 440-6IP Torx Plus or
equivalent
Used with torque driver
See Table 7 Rapid Charger
Used to charge battery and power
phone
0180386A82
Antistatic Mat Kit (includes 66-80387A95
antistatic mat, 66-80334B36 ground
cord, and 42-80385A59 wrist band)
Provides protection from damage to
device caused by electrostatic discharge
(ESD)
6680388B67
Disassembly tool, plastic with flat and
pointed ends (manual opening tool)
Used during assembly/disassembly of
phone
6680388B01 Tweezers, plastic Used during assembly/disassembly
— Digital Multimeter, HP34401A
2
Used to measure battery voltage
8102430Z04 GSM / DCS Test SIM Used to enable manual test mode
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) at (800) 422-4210 or
FAX (800) 622-6210; Internationally, AAD can be reached by calling (847) 538-8023 or by fax (847) 576-3023.
2. Not available from Motorola. To order, contact Hewlett Packard at (800) 452-4844.
1 and 2
V80
6809471A72-O
