6809471A72-O April 14, 2004 41
Level 1 and 2 Service Manual Troubleshooting
Exploded View Parts List
Table 5. Main Assembly Exploded View Parts List
Item
Number
Motorola Part
Number
Description
1 1586821P01 Battery Door
2 SNN5614 Battery Slim Li Ion
3 0309315B07 Back Housing Screws
4 1586818P01 Back Housing
5 728631P01 Camera Module
6 5088017N01 MIDI Speaker 16 MM
7
7586852P02
7586852P03
Keypad Stroke
Keypad Bopomofo
8 5002811Y28 Microphone Assembly
9 8486752P02 Transceiver PC Board
10 0170299N01 Antenna Assembly
Keypad PC Board
E
There is a danger of explosion if the Lithium Ion battery pack is replaced incorrectly.
Replace only with the same type of battery or equivalent as recommended by the
battery manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
