Disassembly/Reassembly Procedures Radio Exploded Mechanical Views and Parts Lists 5-43
Table 5-4. Non Keypad Model Exploded View Parts List
Item Description Part Number
1 Antenna See Chapter 7: Accessories
2 Front Kit Assembly See Table 5-5. Additional Part
List Table
2.01 Front Housing Assembly See Table 5-5. Additional Part
List Table
2.02 Emergency Button 38012008001
2.03 UC Escutcheon 13012035001
2.04 Mic Membrane With Stiffener SL000209A01
2.05 Boot, Microphone SL000208A01
2.06 GPS/GLONASS Antenna See Table 5-5. Additional Part
List Table
2.07 Screw Shoulder, M1.2 X 3.2MM 0371160D01
2.08 Mesh, Speaker SL000217A01
2.09 Speaker AC000028A02
2.10 UC Flex PF000917A01
2.11 Interface Flex PF000915A01
2.12 Speaker Retainer- Grounding Contact
Assembly
0104068J82
2.13 Screw, Thread Forming 0386434Z02
2.14 Microphone 50012012003
2.15 Interface Board 0104065J48
2.16 Screw, Keypad Retainer 0378212A04
2.17 Nameplate, Front 33012037001
2.18 Plain Front Housing Poron 75012131001
2.19 Conductive Pad 75012224001
3 Back Cover Kit Assembly See Table 5-5. Additional Part
List Table
3.01 Screw, Main Board and GOB Board 03012034001
3.02 Option Board Kit See Table 5-5. Additional Part
List Table
3.03 GOB Flex 84012217003
3.04 Flex PF001167A01
3.05 Pad, Thermal 75012234001
3.06 Seal, Top Control 32012269001
3.07 Chassis, Kit 0104065J49

Motorola XPR 7550e Specifications

General

Channel Capacity	1000 channels
IP Rating	IP68
Power Output	VHF: 1-5W, UHF: 1-4W
Digital Protocol	DMR
Bluetooth	Yes
GPS	Yes
Frequency Range	VHF: 136-174 MHz
Display	Full color 5-line display
Dimensions	5.1 x 2.2 x 1.4 in (130 x 55 x 36 mm)
