Parameter Description
Port Switch port number with a fiber connection.
Model Name Moxa SFP/fixed type fiber model name.
Wavelength (nm) Wavelength of the fiber connection.
Vcc (V) Voltage supply to the fiber connection.
Temperature (°C) – Current Fiber connection current temperature.
Temperature (°C) – Max. Fiber connection Max. temperature threshold.
Tx power (dBm) – Current The current amount of light being transmitted into the fiber optic cable.
Tx power (dBm) – Max. The Max. threshold of light being transmitted into the fiber optic cable.
Tx power (dBm) - Min. The Min. threshold of light being transmitted into the fiber optic cable.
Rx power (dBm) – Current The current amount of light being received from the fiber optic cable.
Rx power (dBm) – Max. The Max. threshold of light being received from the fiber optic cable.
Fiber Check Threshold Values
Model Name Temperature
Threshold (°C)
Tx Power (Max./Min.)
(dBm)
Rx Power (Min.)
(dBm)
FEMST 120 -11.0/-23.0 -31.0
FEMSC 120 -11.0/-23.0 -31.0
FESSC 120 3.0/-8.0 -34.0
SFP-1FEMLC-T 120 -5.0/-21.0 -37.0
SFP-1FESLC-T 120 3.0/-8.0 -37.0
SFP-1FELLC-T 120 3.0/-8.0 -37.0
SFP-1GSXLC-T 110 -1.0/-12.5 -18.0
SFP-1GLSXLC-T 120 2.0/-12.0 -19.0
SFP-1GLXLC-T 120 0.0/-12.5 -20.0
SFP-1GLHLC-T 120 1.0/-11.0 -23.0
SFP-1GLHXLC-T 120 4.0/-7.0 -24.0
SFP-1GZXLC-T 120 8.0/-3.0 -24.0
SFP-1G10ALC-T 120 0.0/-12.0 -21.0
SFP-1G10BLC-T 120 -5.0/-21.0 -34.0
SFP-1G20ALC-T 120 1.0/-11.0 -23.0
SFP-1G20BLC-T 120 -5.0/-21.0 -34.0
SFP-1G40ALC-T 120 5.0/-6.0 -23.0
SFP-1G40BLC-T 120 -5.0/-21.0 -34.0
SFP-1GSXLC 100 -1.0/-12.5 -18.0
SFP-1GLSXLC 100 2.0/-12.0 -19.0
SFP-1GLXLC 100 0.0/-12.5 -20.0
SFP-1GLHLC 100 1.0/-11.0 -23.0
SFP-1GLHXLC 100 4.0/-7.0 -24.0
SFP-1GZXLC 100 8.0/-3.0 -24.0
SFP-1GEZXLC 100 8.0/-3.0 -30.0
SFP-1GEZXLC-120 100 6.0/-5.0 -33.0
SFP-1G10ALC 100 0.0/-12.0 -21.0
SFP-1G10BLC 100 -5.0/-21.0 -34.0
SFP-1G20ALC 100 1.0/-11.0 -23.0
SFP-1G20BLC 100 -5.0/-21.0 -34.0
SFP-1G40ALC 100 5.0/-6.0 -23.0
SFP-1G40BLC 100 -5.0/-21.0 -34.0
