Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions
Stream Table
This page displays the multicast stream forwarding status. It allows you to view the status by VLAN ID.
Stream Group: Multicast group IP address
Stream Source: Multicast source IP address
Port: The port that receives the multicast stream
Member Ports: Ports the multicast stream is forwarded to
IGMP Stream Status is only
supported by Moxa’s Layer 3 switches.
01:00:5E:XX:XX:XX) will appear on the Static Multicast Address page. Activate IGMP
Snooping to implement automatic classification
MAC Address
Setting Description Factory Default
Integer Type the MAC address in the MAC Address field to specify a
static multicast address.
None
Member Port
Setting Description Factory Default
Select/Deselect Select the appropriate checkboxes to define the join ports for
this multicast group.
None
