Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions
3-61
DSCP Value and Priority Queues
Setting Description Factory Default
0 to 7
Maps different TOS values to one of 8 different egress queues.
0
8 to 15 1
16 to 23 2
24 to 31 3
32 to 39 4
40 to 47 5
48 to 55 6
56 to 63 7
Rate Limiting
In general, one host should not be allowed to occupy unlimited bandwidth, particularly when the device
malfunctions. For example, so-called “broadcast storms” could be caused by an incorrectly configured topology,
or a malfunctioning device. Moxa industrial Ethernet switches not only prevent broadcast storms, but can also
be configured to a different ingress rate for all packets, giving administrators full control of their limited
bandwidth to prevent undesirable effects caused by unpredictable faults.
Traffic Rate Limiting Settings
There are four types of bandwidth management settings, depending on which model of switch you are using.
Type Model
Type 1 EDS-510E
Type 2 EDS-G508E, EDS-G512E-4GSFP, EDS-G516E-4GSFP, EDS-G512E-8PoE
Type 3 EDS-518E, IKS-6726A, IKS-6728A, IKS-6728A-8PoE
Type 4 IKS-G6524A, IKS-G6824A, ICS-G7526A, ICS-G7826A, ICS-G7528A, ICS-G7828A,
ICS-G7748A, ICS-G7848A, ICS-G7750A, ICS-G7850A, ICS-G7752A, ICS-G7852A
Type 1
For Type 1, the Control Mode setting on the Rate Limiting page can be set to Normal or Port Disable.
Control Mode
Setting Description Factory Default
Normal Set the max. ingress rate limit for different packet types Normal
Port Disable When the ingress multicast and broadcast packets exceed the
ingress rate limit, the port will be disabled for a certain period.
During this period, all packets from this port will be discarded.
