Moxa Technologies EDS-518E User Manual

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions
3-34
Warning Type
Action Description
Trap The EDS E series will send a notification to the trap server when
an
event is triggered.
E-Mail The EDS E series will send a notification to the email server defined
in Email Settings.
Syslog The EDS E series will record a syslog to a syslog server defined in
Syslog Server Settings.
Relay1 The EDS E series supports digital inputs to integrate sensors. When
an event is triggered, the device will automatically activate an
alarm through the relay output.
Event Type
Port Events Description
PoE PD power on Power is being output to the PD.
PoE PD power off The PoE power output is cut off.
PoE over current When the current of the port exceeds the following limits:
802.3 af: 350 mA
802.3 at: 600 mA
High Power: 720 mA
Force: 600 mA
PoE PD Failure Check When the switch does not receive a PD response after the defined
period.
Over Measured Power Limitation When the total PD power consumption exceeds the total measured
power limit.
PoE FETBad When the MOSFET of the port is out of order (please contact Moxa
for technical service)
PoE over Temperature Check the temperature of the environment. If you cannot keep the
temperature under 75°C, contact Moxa for technical support.
PoE VEE Uvlo - VEE (PoE input voltage)
under Voltage Lockout
The voltage of the power supply has dropped below 44 VDC.
Adjust
the voltage to between 46 and 57 VDC to eliminate this issue.
Over Allocated Power Limitation When the total PD power consumption exceeds the total allo
cated
power.
NOTE
The Relay Output does not support three Event Types:
External FET has failed, PSE chip is over
temperature
, and V
EE
(PoE input voltage) under voltage lockout.
