Moxa Technologies EDS-518E - USB Console Configuration (115200, None, 8, 1, VT100)

Managed Ethernet Switch (UI_2.0_FW_5.x) Getting Started
2-2
USB Console Configuration (115200, None, 8, 1,
VT100)
NOTE
A
Moxa switch allows multi-session connections (up to 6) by connecting to the web console and another
console (serial or Telnet) at the same time.
NOTE
We recommend
using PComm Terminal Emulator when opening the USB console. This software can be
downloaded free of charge from the Moxa website.
Before running PComm Terminal Emulator, first install the USB console driver on your PC and then connect the
Moxa switch’s USB console port to your PC’s USB port with a USB cable.
After installing PComm Terminal Emulator, open the Moxa switch’s USB console as follows:
1. From the Windows desktop, click Start

Moxa

PComm Lite Ver1.6

Terminal Emulator.
2. Select Open under the Port Manager menu to open a new connection.
