Chapt er 4 Hardware: MB3280
This chapter provides hardware information for the MGate MB3280.
The following topics are covered:
 Panel Layout
 LED Indicators
 Dimensions
 Jumpers
 Pin Assignments
 DB9 (Male)
 DIN-Rail, Wall Mounting
 Specifications
