Moza Air 2 - Balancing the Roll Axis; Balancing the Pan Axis

7
1
2
1
2
Note: If the balance of the pan axis is not adjusted properly, the pan axis may
become hot, and the inception mode cannot be used properly.
Balancing the Roll Axis
a. Move the roll motor lock switch to the unlock end.
b. Release hands to observe the direction in which the roll axis swings.
c. Loosen the roll axis knob 1 to slide the roll arm 2 until the roll arm 2 stays still.
d. Tighten the knob 1.
Balancing the Pan Axis
a. Grab the Air 2 horizontally, make the pan arm level. Release hands to check
the direction in which the camera swings.
b. Loosen the knob 1 on the pan motor. Move the pan arm 2 leftwards or
rightwards until it keeps level.
c. Tighten the knob 1.
