5
Fix the riser plates in the screw holes on both ends of the quick release plate, then
fix the other quick release plate onto the riser plates in the same way.
Note：If the rod adaptor has been installed before mounting the riser plates,
please remove the adaptor first.
Mounting the Riser Plates
The riser plates need to be used in the follow cases:
a. The camera is too short to balance the tilt axis
b. The lens is too short to install the follow focus
c. The follow focus needs to be installed for zoom
There are also screw holes on the riser plates for installing the rod adaptor.
