20
Specifications
Payload Range
0.3kg~4.2kg
Dimension
230*240*470 mm
Tilt Camera Tray Dimension
110 mm
Roll Camera Tray Dimension
100 mm
Pan Mechanical Endpoint Range
360°
Roll Mechanical Endpoint Range
360°
Tilt Mechanical Endpoint Range
+180°~-95°
Battery Type
INR18650D250
Battery Capacity
2500 mAh
Working Votage
15.2V
Static Current
150mA
BLUETOOTH 4.0 BLE
2.4G
USB
Camera Control Port
Mini USB 5V 1A
Dummy Battery Port
DC2.0mm 7.8V 1A
Accessory Power Supply Port
DC5.5mm 12V 2A
External Power Supply Port
Temperature 0--50℃
DC5.5mm 14.8V 3A
Communication
Air 2
e.Restart the gimbal after the upgrade.
Upgrade via App:
a.Turn off the gimbal.
b. Long press the joystick, then press the power button with your another hand until the
prompt “Boot Mode” appears on the screen.
c.Start App, press Bluetooth to search for Air 2 device and connect.
d. The App will automatically enter the firmware upgrade interface, please wait for the
firmware download to complete, press the ‘upgrade’ button and wait for about 5
minutes.
e. During the upgrade process, ‘upgrading' will be displayed on the gimbal screen,
and' upgrade success' will be displayed on the screen after the upgrade is completed,
and then air 2 can be restarted.
