PRODUCT TECHNICAL MANUAL
FONOMAC 3
V2.20 – 06/2012
11
MTELFONOMAC3220_EN
1.7. Attachments
1.7.1. Induction Loop
Optionally, a Magnetic Induction Loop can be supplied to help people with hearing aids communicate. This
equipment allows the person with a hearing aid to clearly hear any call via the Fonomac 3 telephone.
The Induction Loop kit requires a 220 Vac power supply and is connected to the Fonomac 3 equipment via the
XBUC connector (See Figure 5).
In an electric installation or a complete lift, when the Fonomac 3 is supplied with an Induction Loop, the symbol
identifying it is always included on the information plate to inform about this element presence, as shown in Figure
6.
WARNING: Any other option requiring an induction loop should be expressly mentioned on the order.
FIGURE 6. INFORMATION PLATE OF FONOMAC 3 TELEPHONE WITH INDUCTION LOOP
FIGURE 5. INDUCTION LOOP
