2. TERMINAL PARAMETERISATION
2.1. General Considerations
Fonomac 3 incorporates a set of parameters allowing the user to configure several aspects of the equipment’s
operation.
Fonomac 3 is supplied, by default, with a basic parameterisation which must be completed and/or modified by the
user according to his/her needs.
2.2. Parameters
There are two main groups of parameters:Required Parameters: The user must set a value which is suitable for
these parameters during the Fonomac 3’s set up.
 Advanced Parameters: The user must only modify the default value if necessary.
ID TYPE DESCRIPTION VALUE BY DEFAULT
01 Required 1
st
Alarm Telephone No. 22 digits between 0 and 9 Blank
02 Required 2
nd
Alarm Telephone No. 22 digits between 0 and 9 Blank
03 Required 3
rd
Alarm Telephone No. 22 digits between 0 and 9 Blank
04 Required Test Telephone No. 22 digits between 0 and 9 Blank
05 Advanced
Alarm Telephone No. only
in case the technician is
trapped.
22 digits between 0 and 9 Blank
06 Advanced
Alarm Telephone No. only
for Maintenance
1
22 digits between 0 and 9 Blank
07 Reserved Blank
08 Reserved Blank
09 Reserved Blank
10 Required Fonomac 3 Identifier 10 digits between 0 and 9 Blank
11 Advanced Hardware version Version’s hexadecimal value (read only) Hardware value
12 Advanced Software version Version’s hexadecimal value (read only) Software value
13 Reserved Blank
14 Advanced Synthesizer
0: Not connected
1: Connected
2: Self-detection
2: Self-
detection
15 Required Lift Number Value between 1 and 4 1
16 Advanced Operating mode
0: NC with external filtering (Fonotec, Fonomac II
compatible)
1: NO
2: NC with built-in filtering
3: NO advanced (Fonomac compatible)
2: NC with
built-in filtering
17 Advanced Test call periodicity
0: Deactivated
1-9: Number of days
3 days
18 Advanced Automatic Reply
0: Deactivated
2-9: Number of rings until picked up
3 rings
19 Advanced Special signals function
0: Deactivated
1: ES1, ES2: Inputs
2: ES1: Input; ES2: Output
3: ES1: Input, ES2: control station selector
0: Deactivated
20 Reserved
21 Reserved
22 Advanced
Modernisation Kit (Audio
Kit)
0: Without Modernisation Kit
1: With Modernisation Kit
2: With Modernisation Kit, output of eligible audio
3: With Modernisation Kit, output of eligible audio for
double control station
0: Without
Modernisation
Kit
23 Advanced Detection of busy tone
0: Deactivated
1: Activated with a delay
2: Immediately activated
1: Activated
with a delay
24 Advanced Intercom Mode 0: Deactivated, 1: Activated 0: Deactivated
25 Advanced GSM Mode 0: Deactivated, 1: Activated 0: Deactivated
26 Advanced Communication Protocol
0: Manual (CPMAC)
1: CPC
0: Manual
27 Advanced Detection of engaged line
0: Deactivated
1: Activated
0: Deactivated
28 Advanced
Outgoing line Dialling Code
(0)
0: Deactivated
1: Activated
0: Deactivated
29 Advanced Test call acknowledge
0: Deactivated
1: Activated
1: Activated
1
Alarm caused by low battery or by a special input activation.
