PRODUCT TECHNICAL MANUAL
FONOMAC 3
V2.20 – 06/2012
31
MTELFONOMAC3220_EN
8.2. According to EN81-28 Standard with Via Serie Controller
Key for contacts:
SARI: Inspection box alarm
pushbutton (closed in non-
activated position)
SARF: Car base alarm
pushbutton (closed in non-
activated position)
SAL: Car keypad alarm
pushbutton (closed in non-
activated position)
SARP: Door contact only
closed when door is
completely open
SARN: Magnet auxiliary
contact, closed with lift on
floor (single board only)
KEYPAD
CAR BASE
CAR CEILING
CONTROL
PANEL
L1L3
L1L3
L3L2
L3
L2
M1M3
M1
M3
M3M2
M3
M2
XARP
XBCE2
XARF
XARN
SIB SIS STOPCSIR
SCI
SARI
L1
L3
SARI
M1
M3
SARP
L3
L2
SARF
M3
M2
SARN
XLLT
XMT
XTFN
XTFN
XTFN
XTFN
XPAL
XTFN
TEL
SAL
TNX
XAUX
XCA2
XC11
XC12
XC21
XC22
XRCBUS
XCA1
CLCCHC 24C
24C IN2 IN4
IN3
0Vdc
0Vdc
24C IN10Vdc
XFOT1 XCBUS
0Vdc CLC 24C
CHC
XPSC
-IN +IN
EXC+
EXC-
MALLA
INS
0Vdc CLC 24C
CHC
XADBUS
XCAN
XADBUS
TEL
TNX
24C
CHC
CLC
0V
To Next Page
