Device connection:
FIGURE 9.
CONNECTIONS OF
THE GSM/GPRS LINK
XTFN
Phone
connection
in the
controller
(*) Connections not used with
MP controller
Power supply 230 Vac
connection
Battery
Connector
GSM
Aerial
CAN-BUS
Connector (*)
T
elephone
line connector
for discrete
cable (*)
RS232/RS485/
RS422 BUS
Connector
(
*
)
Digital
Input / Output (*)
Fuse
