MP FONOMAC 3 - Page 38

PRODUCT TECHNICAL MANUAL
FONOMAC 3
V2.20 – 06/2012
38
MTELFONOMAC3220_EN
- Connecting the machine room’s circuit. Using the XVCBUS connector and powering from XNSN or
using the XCON rail connector.
FIGURE 4: CONNECTION OF THE CONSOLE INTO MACHINE ROOM CIRCUIT
brown
blue
grey
black
