6. Saving data from the SD card
to the computer ( EXCEL software )
1) After execute the Data Logger function, take away th
e
SD card out from the " SD card socket " ( 3-18, Fig. 1 ).
2) Plug in the SD card into the Computer's SD card slo
t
( if your computer build in this installation ) or
insert the SD card into the " SD card adapter ". then
connect the " SD card adapter " into the computer.
3) Power ON the computer and run the " EXCEL software ".
Down load the saving data file ( for example the fil
e
name : SLA01001.XLS, SLA01002.XLS ) from the SD
card to the computer. The saving data will present int
o
the EXCEL software screen ( for example as following
EXCEL data screens ) , then user can use those EXCE
L
data to make the further Data or Graphic analysi
s
usefully.
EXCEL data screen ( for example )
