2. SPECIFICATIONS
Circuit Custom one-chip of microprocessor LSI
circuit.
Display LCD size : 52 mm x 32 mm
LCD with green backlight ( ON/OFF ).
Measurement
SPL : Sound pressure level
Type
Leq : Equivalent Continuous Noise Level
Measurement 30 - 130 dB.
Range
Resolution 0.1 dB.
Function dB ( A & C frequency weighting ),
Time weighting ( Fast, Slow ),
Peak hold, Data hold
Record ( Max., Min. ).
Accuracy Characteristics of " A " frequency
(23 ±5 ℃)
weighting network meet IEC 61672
class 2
Under 94 dB input signal, the accuracy
are :
31.5 Hz ±3.5 dB
63 Hz ±2.5 dB
125 Hz ±2.0 dB
250 Hz ±1.9 dB
500 Hz ±1.9 dB
1 K Hz ±1.4 dB
2 K Hz ±2.6 dB
4 K Hz ±3.6 dB
8 K Hz ±5.6 dB
Remark :
The above spec. are tested under the
environment RF Field Strength less
than 3 V/M & frequency less than 30
MHz only.
2
