MRMC TRIGGER BOX - Trigger Box Control Summary

Trigger Box Quick Start Guide
4
To connect the Trigger Box to your external devices you connect wires to
the terminals in pairs. For example:
Trigger Box control summary
Trigger output 2 (OUT 2)
12 V DC power output for general use
Trigger input 2 (IN 2); short these two
External Camera On/Off trigger output
Sync signal input from camera
wires to activate
Buttons for testing
trigger inputs (page 7)
Sync generator speed controls
— coarse and fine adjustment
knobs (page 12)
Controls for testing Flair’s Sync
signal input and External
Camera trigger output (page 12)
