Appendix 1 Troubleshooting
Typical symptoms, causes, and actions
Symptoms Cause and/or action
A trigger output fails
to activate.
The relevant OUT LED
on the Trigger Box fails
to light up.
Check all connections.
Try to isolate the problem:
• In Flair, check that you have assigned the
output trigger to the correct frame (menu
option Setups > Outputs, page 5).
• Make sure the Trigger Box is receiving the
trigger signal from Flair, by checking that
the relevant OUT LED on the Trigger Box
lights up when the trigger is activated in
Flair (page 6).
• Make sure the device you are trying to
trigger is plugged into the correct socket
on the ribbon cable (page 2). The BLOOP
socket does not receive the Camera
Trigger output signal. The TRIGGER
socket does not receive the External
Camera Trigger or Trigger 1 output
signals.
• If it is practical and safe to do so, check
that your external trigger circuitry and
device are working by connecting the
trigger wires to close the circuit.
