Fig. 13 Pulse check after calibration for devices with XCell Pulse technology
3.14 Using the Device with a GALAXY GX2 Automated Test System
(1) Press the button (for more than 1 second) on the device to enter IR mode.
 The device pages begin to display.
(2) Place the device into the suitable GALAXY GX2 test stand.
For further information see the operating manual for the GALAXY GX2
Automated Test System.
Countdown to
finalize
Pulse Check
Waiting for the
user to remove cal
gas screen
WAIT
Is gas
removed?
Span Calibration
Measurement
N
Y
This is a countdown
for the
Pulse Check update
after calibration
