10177245 Rev. 2 / OM-243792 Page 27
Description
Part
No.
Item
No. Quantity
Figure 10-1. Digital Elite Series (Quick Release Models):
Elite Auto-Darkening, VSi Auto-Darkening,
And Passive Welding Helmets
1 * Helmet Shell, Black (Includes Item 6) 1.................... ...... ................
216714 Label, Warning Helmet En/Sp/Fr 1................ ...... ....................
2 10177663 Lens Cover, Inside (4-1/4 X 2-1/2 in.) (Elite) 1............ ...... ..........
2 10177666 Lens Cover, Inside (4-1/4 x 1-3/4 in. in (VSi) 1............ ...... ..........
2 10177667 Lens Cover, Inside 4 1/2 In. X 5 1/4 In. (Passive) 1............ ...... ......
3 * Auto-darkening Lens Assembly, Elite 1.................... ...... ................
3 * Auto-Darkening Lens Assembly, VSi 1.................... ...... ................
3 10177646 Filter Plate, #10 4 1/2 In. X 5 1/4 In. (Passive) 1............ ...... ........
4 * Gasket, Lens Assembly, Elite 1.................... ...... ......................
4 * Gasket, Lens Assembly VSi 1.................... ...... .......................
4 * Gasket, Passive Lens 1.................... ...... ............................
5 10177662 Lens Cover Outside (4-11/16 X 5-5/8 in.) (5 Per Pkg.) 1............ ...... ..
6 * Front Lens Holder (Black) 1.................... ...... .........................
7 * Battery Tray Kit (Left/Right), Elite 1.................... ...... ...................
7 * Battery, Cover (VSi) 1.................... ...... ..............................
* Battery, Lithium (CR2450) 2...................... ...... .........................
♦10177024 Adapters, Non-Slotted Hard Hat (Not Shown) 1.............. ..... .........
♦10177022 Adapters, Slotted Hard Hat (Not Shown) 1.............. ..... .............
8 ♦10177648 Lens, 1.25 Magnification 1............ ..... ..........................
8 ♦10177649 Lens, 1.50 Magnification 1............ ..... ..........................
8 ♦10177650 Lens, 1.75 Magnification 1............ ..... ..........................
8 ♦10177661 Lens, 2.00 Magnification 1............ ..... ..........................
♦Optional
*For components with no part number listed, please contact the Miller Customer Service Center @
1-866-931-9730.
