MSA Elite Series - Specifications

10177245 Rev. 2 / OM-243792 Page 4
SECTION 2 − SPECIFICATIONS
Specification
Elite
With Digital Elite ADF
PN10177018
Elite
With VSi
ADF
PN10177017
Classic
Series
With FS10
ADF
PN10177020
Viewing Field 3.81 x 2.36 in.
(97 x 60 mm)
3.75 x 1.57 in.
(95 x 40 mm)
3.75 x 1.375 in.
(95 x 35 mm)
Operating Modes Four Modes: Weld, Cut,
Grind, X-Mode
Two Modes:
Weld, X-Mode
One Mode:
Weld
Reaction Time 0.0000500 sec (1/20,000) 0.00007 sec
(1/15,000)
0.000277 sec
(1/3600)
Available Shades
All Shades Provide
Continuous UV And IR
Protection.
Weld Mode
Darkened State:
No. 8 − No. 13
Light State: No. 3
Cut Mode
Darkened State:
No. 5 − No. 8
Light State: No. 3
Grind Mode
Light State: No. 3
X-Mode
Darkened State:
No. 8 − No. 13
Light State: No. 3
Darkened
State:
No. 8 − No. 13
Light State:
No. 3
Darkened
State:
No. 10
Light State:
No. 3
Sensitivity Control
Adjustable For Varying
Ambient Light And Welding/
Cutting Arc.
No. 10 Setting Locks Lens
In Dark State.
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
X-Mode:
No. 0 − No. 10
Adjusts for
Varying Ambi-
ent Light And
Welding Arc;
X-Mode
Not Applicable
Delay Control
Slows Lens Dark-To-Light
State.
Weld Mode:
No. 0 − No. 10
Cut Mode:
No. 0 − No. 10
Grind Mode:
Not Applicable
X-Mode
No. 0 − No. 10
Slows Lens
Dark-To-Light
State (Between
0.1 And 1 Sec-
ond)
Not Applicable
Automatic Power Shuts Lens Off 45 Minutes
After Last Arc Is Struck.
Lens Automatically Turns
On When Arc Is Struck.
Shuts Lens Off 15−20 Minutes
After Last Arc Is Struck.
Low Battery Light Red LED Illuminates To Indicate 2−3 Days
Remaining Battery Life.
Not Applicable
