MSA ULTIMA X5000 User Manual

3 Installation
3.1 InstallationWarnings-ReadBeforeInstallation
WARNING!
• Refertomanualaddendum(P/N10182779)forcertificationinformationandadditionalsafetyinformationbefore
installationandoperation.
• WhenutilizingtheP+FWirelessHARTBulletaccessory,readandunderstandthequickstartguides(P/N10218978
and10218979)andP+FWirelessHARTBulletinstructionmanual(WHA-BLT-F9D0-N-A0-*)beforeinstallingand
using.TheP+FWirelessHARTBulletshallbeinstalledasclosetotheX5000transmitter,junctionboxorJB5000as
possible.
• Somedigitalsensorsareprovidedinafritlesssensorhousing.ThefritlesssensorhousingislabeledasDiv2orZone
2andisapprovedforDiv2orZone2installationsonly.TheprotectionmethodisNon-incendiveorTypen
respectively.Ensureallcomponentsareapprovedforthewiringmethodbeingusedandinaccordancewiththe
NationalElectricalCodeofthecountryofuse,anyapplicablelocalregulations,thismanualandtheaddendumtothe
manual.
• Aspartoftheproductcertification,itwasverifiedthatoptionalcommunicationfunctionsofthisgasdetection
instrumentwhileoperatingatthemaximumtransactionratedonotadverselyaffectthegasdetectionoperationand
functionsoftheinstrument.Theproductcertification,however,doesnotincludeorimplyapprovaloftheSafeSwap
feature,communicationsprotocolorfunctionsprovidedbythesoftwareofthisinstrumentorofthecommunications
apparatusandsoftwareconnectedtothisinstrument.
• Followthewarningsbelowwhenremovingorreplacingsensors.ReferenceFigure3forcomponentoverview.
○ NeverremoveorreplaceasensorbodyassemblyoranUltimaXIRPluswhileunderpowerorwhenexplosive
hazardsarepresent.
○ ConfirmthattheareaisfreeofexplosivehazardsbeforeremovingorreplacinganXCellSensorunderpower.
○ ToremoveanXCellSensor,unscrewXCellSensorthreefullturns,wait10seconds,andthenremovetheXCell
Sensorcompletely.
• Plugallunusedconduitentrieswithasuitablycertifiedblanking/stoppingplug.
• Donotpaintthedevice.AvoidpaintinginareaswheretheULTIMA

X5000andremotesensorjunctionboxare
located.IfpaintingisrequiredinanareawhereanULTIMA

X5000orremotesensorhasbeeninstalled,exercise
cautiontoensurepaintisnotdepositedonthesensorinletfitting.Paintsolventscanalsocauseanalarmconditionto
occurorpotentiallypoisonelectrochemicalsensors.
• TheH
2
SDigitalSensormaybeadverselyaffectedbythefollowingsubstances:
○ Alcohols(methanol,ethanol,isoproponal)
○ Nitrogendioxide(NO
2
)
○ Chlorine(CI
2
)
○ Paintsolvents(acetone,turpentine,toluene,mineralspirits,etc.)
• TheCODigitalSensormaybeadverselyaffectedbythefollowingsubstances:
○ Alcohols(methanol,ethanol,isoproponal)
○ Paintsolvents(acetone,turpentine,toluene,mineralspirits,etc.)
• TheO
2
DigitalSensormaybeadverselyaffectedbythefollowingsubstances:
○ LongtermexposuretolowlevelsofAcetylene
US Ultima X5000 Gas Monitor 12
3 Installation

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
