MSA ULTIMA X5000 - Status Menu Overview; Calibration Process

4.3 StatusMenu
ThefollowingsettingscanbeviewedthroughStatusMenuwithoutapassword,regardlessofwhetheroneisenabled.
1. ScrollandselectStatus.
2. Use↓toscrollthroughthelist:
○ Tag#
○ SoftwareVersion
○ InputVoltage
○ SensorType
○ LifeandHealth
○ PreviousCalibrationDatesAlarmSetup
○ Alarm1SetPoint
○ Alarm1Actions
○ Alarm2SetPoint
○ Alarm2Actions
○ RelaySetup
○ MappingEnergyState
○ BluetoothTagID
3. Use→togobacktothemainmenu.
4.3.1 LifeandHealth-XCellH
2
SandCOSensorswithTruCalOnly
TheLifeandHealthinformationreportsthegeneralhealthofthesensor.XCellsensorswithTruCal(HydrogenSulfideand
CarbonMonoxide)calculatecurrentsensorsensitivityusingautomatedpulsechecks.Thepulsestimulatesthesensorwith
aresponsesimilartohavingactualcalibrationgasapplied.Thestimulatedresponseiscomparedtothelastcalibrationand
willmakeadjustmentstosensitivitytomatchthelastcalibration.Whentherequiredadjustmentisgreaterthantheaccuracy
ofthealgorithm’sadjustment,thesensorwillcallforacalibration.
Alldigitalsensors,includingcatalyticbeadandoxygen,willshowlifehealthstatusas'Good'or'Fair'withthe
followingcalculation:
Goodconditionoccurswhenthecurrentcalibratedspansensitivityisgreaterthan50%ofthewaybetweenthe
initialcalibrationsensitivityandtheend-of-lifespansensitivity.Fairconditionoccurswhenthecurrentcalibrated
spansensitivityislessthan50%ofthewayfromtheinitialcalibrationsensitivityandtheendoflifespan
sensitivity.
NOTICE
Usingexpiredcalibrationgasortheincorrectcalibrationgascanresultinapremature"Fair"status.
5 Calibration
Calibrationistheprocessofapplyingaknownquantityofgastothetransmittersothatthetransmittercanadjustthe
precisionandaccuracyofthemeasurementsmadeinnormaloperatingmode.Thisprocessensuresthatgas
measurementsareasaccurateaspossible.
US Ultima X5000 Gas Monitor 59
5 Calibration
