MSA ULTIMA X5000 User Manual

10 Appendix:GeneralCertificationInformation
Refertomanualaddendum(P/N10182779)foradditionalCertificationInformation.
WARNING!
Sometoxicgasesareprovidedinafritlesssensorhousing.ThefritlesssensorhousingislabeledasDiv2orZone2andis
approvedforDiv2orZone2installationsonly.TheprotectionmethodisNonincendiveorTypenrespectively.Ensureall
componentsareapprovedforthewiringmethodbeingusedandinaccordancewiththeNationalElectricalCodeofthe
countryofuse,anyapplicablelocalregulations,thismanualandtheaddendumtothemanual.Failuretofollowthiswarning
canresultinseriousinjuryorlossoflife.
Figure 54 Digital Sensor for Div 1 & 2, Zone 1 & 2 (Left) vs Digital Sensor for Div 2, Zone 2 only (right)
FMAPPROVAL
ThisApprovaldoesnotincludeorimplyApprovalofapparatustowhichthesubjectinstrumentmaybeconnected.Inorder
tomaintainanFMApprovedsystem,theapparatustowhichthisinstrumentisconnected,mustalsobeApprovedbyFM
Approvals.AspartofthisApproval,itwasverifiedthatoptionalcommunicationfunctionsofthisgasdetectioninstrument
whileoperatingatthemaximumtransactionratedonotadverselyaffectthegasdetectionoperationandfunctionsofthe
instrument.ThisApproval,however,doesnotincludeorimplyApprovalofthecommunicationsprotocolorfunctions
providedbythesoftwareofthisinstrumentorofthecommunicationsapparatusorsoftwareconnectedtothisinstrument.
TheUltimaX5000Transmitter,X5000JunctionBox,UltimaXIRPlusandDigitalSensors(H
2
S,500ppmH
2
S,CO,O
2
,
Combustibles)alsohaveFMPerformanceApprovalforuseinordinary(non-hazardous)orhazardouslocations.
ThefollowinginformationshallbenotedforFMApprovedconfigurations:
• TheFMApprovedDigitalSensorshaveanIP65andTYPE3Xenvironmentalrating,howeverifwaterissplashedonto
thefrit(alsoreferredtoasaflamearrestor),thesensormaynotbeabletodetectgasforaperiodofupto12minutes.
Ifwaterissplashedontothiselement,useaclothorpapertoweltodabthefritinordertoabsorbanyexcesswater.
• TheFMApprovalrequiresthatpasswordprotectionforBluetoothbeenabled.
• TheDigitalSensor(O
2
)isnottobeusedinenvironmentscontaining5%(v/v)ormoreofCarbonDioxide.
• TheDigitalSensor(O
2
)isunaffectedbyairvelocitiesofupto5m/s
• TheresponseandrecoverytimesfortheDigitalSensor(H
2
S,500ppmH
2
S,CO,O
2
)areasfollows:
US Ultima X5000 Gas Monitor 92
10 Appendix: General Certification Information

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
