11 Appendix:HARTSpecificInformation
TheULTIMAX5000GasMonitorisavailablewithanoptionalHART(HighwayAddressableRemoteTransducer)output
communicationsprotocol.Withthisoption,theULTIMAX5000complieswithHARTProtocolRevision7.
AllavailablestatusbytesaredefinedintheX5000HARTSpecificationfoundontheproductCD.Refertothatdocumentfor
completeHARTcommandandstatusdefinitions.UsetheHARTdigitalinterfacetoquerytheunittoprovideadditional
troubleshootinginformation.
Table 24 Device Identification
ManufacturerName MineSafetyAppliances,Inc(MSA) ModelName ULTIMAX5000
HARTIDCode 227(0xE3) DeviceTypeCode 46(0x2E)
HARTProtocol-Revision 7 DeviceRevision


1
NumberofDeviceVariables 2 
PhysicalLayersSupported FSK 
US Ultima X5000 Gas Monitor 94
11 Appendix: HART Specific Information

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
