MSA ULTIMA X5000 User Manual

Figure 2 ULTIMA X5000 Interface
2.3 Bluetooth
®
WirelessTechnology
TheULTIMA

X5000canbeorderedwithBluetoothcommunication.UsingtheX/SConnectApponanappropriatesmart
phoneortablet,youareabletointerfacewiththeULTIMA

X5000inalargerandmoreuserfriendlysetting.Connectingvia
Bluetoothenablescommunicationwithtransmitterupto70feet(21m)away.
WARNING!
Bluetoothoperationisdependentuponsignalavailabilityofthewirelessservice(s)necessarytomaintainthe
communicationlink.Lossofwirelesssignalwillpreventcommunicationofalarmsandotherinformationtolinkeddevices.
Takeappropriateprecautionsintheeventalossofwirelesssignaloccurs.
Failuretofollowthiswarningcanresultinseriouspersonalinjuryordeath.
IfthedevicewasnotorderedwithBluetoothitcannotbeupgraded.
IforderedwithBluetooth,thedevicewillbeshippedwithBluetoothenabled.See4Operationforinstructionson
disablingBluetooth.
TheULTIMA

X5000anduserprovidedcommunicationdevicewillneedtobepaired.Thisrequiresbothdevicestobein
rangeandforapairingsequenceinputtinga6digitpairingcode.Theinstructionswillbedisplayedonboththe
ULTIMA

X5000andcommunicationdevice.
Therearecommunicationdevicescapableofbeingusedinclassifiedareas.PleasecontactyourMSA
representativeforadditionalinformation.
2.4 DualSensing
TheULTIMA

X5000iscapableofcommunicatingwithanddisplayinginformationfortwosensorsatatime.Thereareno
restrictionstothetypeofsensorsconnectedtothedevice.
TheULTIMA

X5000GasMonitorgeneratestwodiscreteanalogoutputs;oneforeachsensorconnectedtothetransmitter.
TheanalogoutputassociatedwithSensor1alsohasthedigitalHART(HighwayAddressableRemoteTransducer)
communicationsuperimposedontheanalogsignal.Iftwosensorsareconnected,thedigitalHARTcommunicationcarries
informationforbothsensors.
2.5 RetrofitInstallations
TheULTIMA

X5000hastheconduitentrieslocatedintheexactsameorientationanddistancefromthewallandthe
mountingholesforattachingtoawallareidenticaltotheUltimaX.
US Ultima X5000 Gas Monitor 8
2 Description

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
