MSA ULTIMA X5000 User Manual

Priority
1
Display
Message
StatusLEDs
(G/Y/R)
Latch
Condition
Description Resolution
N/A Fullscalevalue
and“LOC”
displayedon
thelower
displayareas
pereach
sensor
ON/ON/OFF Latch Indicatesa
combustible
sensorsoverrange
conditionwas
measured.
Acknowledgethe
sensor,waitforthe
warmuptimeperiod
andrecalibratethe
sensor.
N/A Gasvalueis
stillshown.
Bothside
greenLEDs
blinking
N/A Indicatesthat
calibrationis
recommended.
(TruCalsensors
only)
Calibratethesensors
attachedtotheunit.
11 Parameter
Fault(Sensor)
ON/ON/OFF Latch Indicatesthata
settingisimproperly
setintheunit.
Resetthesensors
datasheets.Verifyany
customersettings.
Thenrecalibratethe
sensor.
1
Lowernumbershavehigherpriority
US Ultima X5000 Gas Monitor 77
6 Maintenance

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
