MSA ULTIMA X5000 User Manual

SensorOptions

CO H
2
S SO
2
CL
2
NO
2
H
2
S
500PPM
Hydrogen1000
PPM
NH
3
-100
PPM
NH
3
-1000
PPM
SO
2
-100
PPM
SafeSwap Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
RemoteMount
Distance
100m 100m 100m 100m 100m 100m 100m 100m 100m 100m
Power:SingleSensor 2.8W 2.8W 2.8W 2.8W 2.8W 2.8W 2.8W 2.8W 2.8W 2.8W
Power:DualSensing 3.6W 3.6W 3.6W 3.6W 3.6W 3.6W 3.6W 3.6W 3.6W 3.6W
*ExtendedRange    None -40°Cto
+50°C
None -40°Cto+60°C None  -40°Cto
+60°C

SensorOptions

Oxygen LowOxygen CombustibleCatalytic XIRPLUSCombustibles XIRPLUSCarbonDioxide
OperatingRange
2
-40°Cto+60°C -20°Cto+50°C -40°Cto+60°C -40°Cto+60°C -40°Cto+60°C
Storage -40°Cto+60°C -20°Cto+40°C -40°Cto+60°C -40°Cto+60°C -40°Cto+60°C
ZeroDrift
1
0.2%Volperyear <1%FSpermonth <5%LELperyear NotApplicable NotApplicable
SpanDrift
1
0.2%Volperyear <2%FSpermonth <5%LELperyear NotApplicable NotApplicable
Noise
1
<2displayunits <2displayunits 1%LEL 1%LEL 0.05%
Repeatability
1
<±1% <±10% ±1% ±1% ±1%
Resolution 01%Vol 0.10% 1%LEL 1%LEL <0.05%
T90 <11s <30s <22s <2s <6s
Humidity 10-95% 10-90% 10-95% 15-95% 15-95%
ExpectedSensorLife 5years 2yearsinair 5years 10years 10years
Warranty 3years 1years 3years electronics:5years
IRsourcebulb:10years
8 Appendix: Specifications
ULTIMA® X5000 81

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
