MSA ULTIMA X5000 User Manual

Compound Vol%
forNA
LEL
Vol%
forEN
LEL
Linearity
Curve/Table
CalGas NA
Span
Value
EN
Span
Value
1,4-Dioxane 2.0 n.a. 4 0.6%Propane 42% n.a.
1,3-Dioxolane 2.1 2.3 2 0.6%Propane 35% 32%
Epichlorohydrin 3.8 2.3 6 0.6%Propane 46% 76%
Ethane 3.0 2.4 3 0.6%Propane 25% 31%
Ethanol 3.3 3.1 6 0.6%Propane 35% 37%
EthylAcetate 2.0 2.0 6 0.6%Propane 60% 60%
EthylAcrylate 1.4 1.4 8 0.1%Propane 15% 15%
EthylBenzene 0.8 1.0 8 0.1%Propane 15% 12%
EthylChloride 3.6 3.6 2 0.6%Propane 27% 27%
Ethylene 2.7 2.3 8 1.35%Ethylene 50% 59%
EthyleneDiamine 4.2 2.5 8 0.1%Propane 17% 29%
EthyleneGlycol
MonomethylEther
1.8 1.8 6 0.6%Propane 60% 60%
EthyleneOxide 3.0 2.6 6 0.6%Propane 65% 75%
Gasoline(asHexane) 1.1 1.0 6 0.6%Propane 41% 45%
Heptane 1.1 0.85 2 0.6%Propane 35% 45%
Hexamethyldisiloxane
(HMDS)
0.5 0.5 8 0.1%Propane 22% 22%
Hexane 1.1 1.0 6 0.6%Propane 41% 45%
1-Hexene 1.2 1.2 6 0.6%Propane 38% 38%
Isobutane 1.8 1.3 2 0.6%Propane 30% 42%
IsobutylAlcohol 1.7 1.4 6 0.6%Propane 41% 50%
IsobutylIsobutyrate(IBIB) 1.0 0.8 1 2.5%Methane 25% 31%
Isobutylene 1.8 1.6 6 0.6%Propane 62% 70%
Isooctane 1.1 0.7 4 0.6%Propane 28% 44%
Isopropanol 2.0 2.0 6 0.6%Propane 48% 48%
IsopropylAcetate 1.8 1.7 6 0.6%Propane 57% 60%
IsopropylAmine 2.0 2.3 6 0.6%Propane 41% 36%
JP-5 0.6 n.a. 6 0.6%Propane 41% n.a.
Methanol 6.0 6.0 3 0.6%Propane 23% 23%
Methoxypropylamine 2.3 2.3 6 0.6%Propane 55% 55%
MethylAcetate 3.1 3.1 5 0.6%Propane 46% 46%
MethylAcrylate 2.8 1.95 6 0.6%Propane 68% n.a.
MethacrylicAcid 1.6 2.1 2 0.6%Propane 55% 42%
89 Ultima X5000 Gas Monitor US
9 Appendix: Calibration Guide for Additional Gases

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
