Appendix 38
6.2 Specifications
6.2.1 MESO QuickPlex SQ 120 Instrument Specifications
All performance information given below, including standard signal levels, detection limits, dynamic range, and instrument noise, is
based on 150 µL read volumes in 96-well MULTI-ARRAY plates using standard plate read parameters.
Table 6:2 Specifications
Signals generated by Free TAG, 15,000
Signals generated by PQ Low Control
12,000–18,000 counts
25–100 counts
Dynamic Range >10
5
Standard Deviation of Dark Noise (one spot plates)
0–16 counts
96-well SECTOR Plate (singleplex and multiplex) 1 minute, 30 seconds
96-well QUICKPLEX plate (singleplex and multiplex) 2 minutes, 45 seconds
Environmental Specifications
Operational Temperature Range 20–26 °C (68–78 °F)
Operational Humidity Range 10–80 % relative humidity (non-condensing)
Storage Conditions
-18–50 °C (0–122 °F) at 85 % relative humidity
(non-condensing)
Ambient Light <2000 lux with no exposure to direct sunlight
Voltage 100–240 V~ 50/60 Hz
Current 1.7–0.7 A
Power Consumption 170 W
Instrument Power Requirements*
Voltage 24 VDC
Current 6 A
Size 13 in x 23 in x 21 in (33 cm x 58 cm x 53 cm)
Weight 44.5 lb (20.2 kg)
Plate Standard Read Volume
96-well MULTI-ARRAY/MULTI-SPOT Plates
150 µL
Custom Barcode Compatibility
Code 39, Code 128 Minimum line width: 7 mils
*an approved low voltage power adapter must be used with the product to modify the input power to the instrument power
