1-3
Getting Started
Onboard IDE
h An IDE controller on the ICH4 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA100/66/33 operation modes.
h Can connect up to four IDE devices.
On-Board Peripherals
h On-Board Peripherals include:
- 1 x floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 2 x serial ports (COM A + COM B)
- 1 x parallel port supports SPP/EPP/ECP mode
- 1 x RJ-45 LAN port
- 2 x SCSI connectors
- 2 x IEEE 1394 ports (Rear x 1/Front x 1) provided by add-in card (Optional)
- 4 x USB 2.0 ports (Rear x 2/Front x 2)
Onboard SCSI
h Integrated LSI 53C1030 Ultra320 SCSI controller.
h Supports dual channels.
Onboard LAN
h Integrated Broadcom
®
BCM5703CKHB Gigabit Ethernet controller.
h 64bit/100MHz PCI-X bus interface.
Onboard Audio
h AC’97 audio codec integrated in ICH4 south bridge.
h AD 1885 software audio codec.
h Vertical audio phonejacks (MIC, Line-In, Line-Out) onboard.
Video Add-In Card (Optional)
h ATI Rage™ XL video controller with 8MB memory.
h Mini PCI interface.
IEEE 1394 Add-In Card (Optional)
h TI TSB43AB22 1394a Link Layer Controller.
h Mini PCI interface.
