1-2
MS-9121 E-ATX Mainboard
Mainboard Specifications
CPU
h Supports single/dual Intel
®
Xeon™ processors with 512K L2 cache.
h Supports 1.8GHz ~ 2.8GHz and up.
Chipset
h Intel
®
E7505 North Bridge
- Supports 100MHz/133MHz system clock.
- Intel
®
NetBurst micro-architecture supports 400MHz/533MHz system bus.
- System bus bandwidth of 3.2GB/s & 4.27GB/s.
- Supports DDR266/200 memory.
- Supports AGP 8x/4x.
h Intel
®
ICH4 South Bridge
- Hi-Speed USB (USB2.0) controller, 480Mb/sec.
- 2 channel Ultra ATA 100 bus Master IDE controller.
- PCI Master 2.2.
- I/O APIC.
- AC’97 2.2 interface.
- 3 UHCI Host controllers and 1 EHCI Host controller.
h Intel
®
P64H2 chipset
- Supports 64-bit PCI-X slots at 100MHz..
- Connects directly to the MCH and provides a dedicated path for high
performance I/O.
Main Memory
h Supports eight memory banks using four 184-pin DDR DIMMs.
h Supports up to 8GB PC2100/PC1600 DDR SDRAMs.
h Supports 2.5v DDR SDRAM.
Slots
h 1 x 8X AGP Pro (50 Watts) slot.
h 1 x 64bit/100MHz PCI-X slot with support for Zero Channel RAID (PCIX3).
h 3 x 64bit/100MHz PCI-X slots.
h 1 x 32bit/33MHz PCI slot.
h 1 x mini PCI slot.
h PCI 2.2, PCI-X, and AGP 3.0 compliant.
