2-6
MS-9121 E-ATX Mainboard
Memory
The mainboard provides 4 slots for 184-pin DDR DIMM (Double In-
Line Memory Module) modules and supports the memory size up to 8 GB.
You can install PC2100/DDR266 or PC1600/DDR200 DDR SDRAM mod-
ules on the DDR DIMM slots (DIMM 1~4).
DDR DIMM Slots
(DIMM 1~4)
DIMM Module Combination
Install at least two DIMM modules on the slots. Each DIMM slot sup-
ports up to a maximum size of 2GB. You can install either single- or double-
sided modules to meet your own needs, but memory modules must be in-
stalled on the board IN PAIRS.
Memory Speed/CPU FSB Support Matrix
DDR200 DDR266
400MHz FSB Yes Yes
533MHz FSB No Yes
