MSI E7505 Master-LS2 - Interrupt Request Routing

2-29
Hardware Setup
Interrupt Request Routing
The IRQ, acronym of interrupt request line and pronounced I-R-Q, are
hardware lines over which devices can send interrupt signals to the
microprocessor.
DEVICE INT A# INT B# INT C# INT D#
AGP PIRQA_L PIRQB_L N/A N/A
PCI Slot 1 PIRQF_L PIRQG_L PIRQH_L PIRQE_L
PCI Slot 2 (Mini PCI) PIRQG_L N/A N/A N/A
P64H2 PIRQC_L N/A N/A N/A
LSI53C1030 PAIRQ8 PAIRQ9 N/A N/A
PCI-X Slot 3 (SCSI RAID) PAIRQ0 PAIRQ1 N/A N/A
PCI-X Slot 4 PAIRQ4 PAIRQ5 PAIRQ6 PAIRQ7
GIGABIT LAN PBIRQ0 N/A N/A N/A
PCI-X Slot 1 PBIRQ4 PBIRQ5 PBIRQ6 PBIRQ7
PCI-X Slot 2 PBIRQ8 PBIRQ9 PBIRQ10 PBIRQ11
MS-9513 (VGA Card) PIRQG_L N/A N/A N/A
MS-9514 (1394 Card) PIRQG_L N/A N/A N/A
