3-16
MS-6702E ATX Mainboard
Set Super I/O
Press <Enter> to enter the sub-menu screen.
Floppy Controller
This is used to enable or disable the onboard Floppy controller.
Serial Port A
These items specify the base I/O port addresses of the onboard Serial Port A
(COM A). Selecting [Auto] allows AMIBIOS to automatically determine the
correct base I/O port address. Settings: [Auto], [3F8/COM1], [3E8/COM3],
[2E8/COM4] and [Disabled].
IR Function
This is used to enable or disable the operation mode for serial port 2. Setting
options: [Enabled], [Disabled].
IR Mode
When IR Function is set to [Enabled], this setting allows you to specify
the operation mode for serial port 2. Setting options: [1.6uS], [3/16 Baud],
[ASKIR].
Option Description
Auto BIOS will automatically determine whether to enable
the onboard Floppy controller or not.
Enabled Enables the onboard Floppy controller.
Disabled Disables the onboard Floppy controller.
