3-17
BIOS Setup
Parallel Port
This field specifies the base I/O port address of the onboard parallel port.
Selecting Auto allows AMIBIOS to automatically determine the correct base
I/O port address. Settings: [Auto], [Disabled], [378], [278], [3BC].
Parallel Port Mode
This item selects the operation mode for the parallel port. Settings: [Normal],
[Bi-Dir], [EPP], or [ECP].
EPP Version
The item selects the EPP version used by the parallel port if the Parallel
Port Mode is set to [EPP] mode. Settings: [1.7], [1.9].
IRQ
When Parallel Port is set to [Auto], the item shows Auto indicating that
BIOS determines the IRQ for the parallel port automatically.
DMA Channel
This feature needs to be configured only when Parallel Port Mode is
set to the [ECP] mode. When Parallel Port is set to Auto, the field will
show [Auto] indicating that BIOS automatically determines the DMA chan-
nel for the parallel port.
