5
Specifications
Specifications
CPU
Supports 12th Gen Intel® Core™, Pentium® Gold and
Celeron® Processors*
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® Z690 Chipset
Memory
2x DDR5 memory slots, support up to 64GB*
Supports 1R 4800 MHz (by JEDEC & POR)
Max. overclocking frequency:
1DPC 1R Max speed up to 6800+ MHz
1DPC 2R Max speed up to 5600+ MHz
Supports Intel® XMP 3.0 OC
*Please refer to www.msi.com for more information on compatible memory
USB
Intel® Z690 Chipset
panel
4x USB 3.2 Gen2 10Gbps ports on the back panel
Hub ASM1074
4x USB 3.2 Gen1 5Gbps ports available through
internal USB connectors
4x USB 2.0 ports available through internal USB
connectors
Expansion Slot
2x PCIe x16 slots (From CPU)
Support PCIe 5.0
Support x16/ x0, x8/ x8
1x PCIe x4 slot (From Z690 Chipset)
Supports PCIe 3.0 x4
Continued on next page
