131

ATX_PWR1

1 +3.3V 13 +3.3V

2 +3.3V 14 

3 Ground 15 Ground

4 +5V 16 

5 Ground 17 Ground

6 +5V 18 Ground

7 Ground 19 Ground

8 PWR OK 20 Res

9 5VSB 21 +5V

10 +12V 22 +5V

11 +12V 23 +5V

12 +3.3V 24 Ground

4 1

CPU_PWR1~2

1 Ground 5 +12V

2 Ground 6 +12V

3 Ground 7 +12V

4 Ground 8 +12V



󼜃󼒆󻺞󽍟

󻢚󻋒󼗶󼓂󼳲󼕦󻰆󼕦󼗶󼓂󺫧󺯻󼖗󼱊󼏂󼐞󻨆󻝦󺩾󼏢󺪢󻈊󼎦󻡆󼕪󻫦󻋎󺧲󼌺󼘇󼗳󼔮󻙎

󼖃󻇋󽍊󻂆󼞲󽑇󼕪󽍊󼃟󼃎󼐖

󼗶󼓂󼳖󺼗󼼢

󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󼓂󺫧󺯻󼖗󼱊󻝮󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖

MSI MEG Unify-X Z690 User Manual
