Overview of Components
SATA5~8 & SATAA~B1: SATA 6Gb/s Connectors
These connectors are SATA 6Gb/s interface ports. Each connector can connect to one
SATA device.
SATA5
SATA7
SATAA
SATA6
SATA8
SATAB1
Important
transmission otherwise.
SATA cables have identical plugs on either sides of the cable. However, it is
recommended that the flat connector be connected to the motherboard for space
saving purposes.
8. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
8
8
To Next Page
