33
Overview of Components
JOC_RT1: OC Retry Button Connector
This connector allows you to connect a button. When you press and hold the button,
the system will keep retrying OC items until it boot up successfully.
Normal
(default)
Boot with the saved
BIOS settings.
Normal
(default)
Enabled
Apply the BIOS default
settings and lower PCIe
(from CPU) mode for
Safe Boot
Retry OC
JOC_RT1
JOC_FS1: Safe Boot Jumper
This jumper is used for Safe Boot. Once enabled, the system will boot with default
settings and lower PCIe (from CPU) mode.
